Get a quote for a prefabricated home shell in a few clicks

Saving time with design software

With the GeoFrame software program, contractors can easily configure precast concrete airframes for serial housing construction, obtain quotes, place orders and have these airframes delivered to the construction site in the foreseeable future. Especially in the preparation phase, this allows contractors to save a lot of time, according to MBS Group, which developed the software. The contractor or architect can easily link their own IFCs to the configuration.

GeoFrame is easy to use and is based on fourteen basic models: townhouses, corner houses, senior citizen houses and semi-detached houses, in one, two or three layers and with a flat roof or a gable roof. "Then you can choose a number of width and depth dimensions, add an extension of 1.20 or 2.40 meters and possibly add insulation and window frames, and the shell is ready," says Victor Woesthuis, marketing manager at MBS Group. "With this, more than 150 different airframes can be made. Everything we have made in recent years for serial housing construction can be configured with this. The big advantage is that it allows a contractor to have the initial stage of preparation ready in no time and the request for quotation can go out the door."

Saving time in the preliminary process

The idea for the software originated two years ago at an office of MBS Group, which, with production sites in Alphen aan den Rijn and Soest, is a major player in the field of precast concrete products. Woesthuis: "Soon after I joined MBS, I went through the engineering process together with the calculator and then you discover that a relatively small adjustment in a shell has many consequences and costs a lot of calculation time. If we standardize this, it can be avoided and the contractor can be relieved of a lot of work in the preliminary phase. We then took this up with Innobrix, which is strong in visualizing buildings and supporting residents in configuring their new homes. So Innobrix works mainly on the back end of the process, we on the front end. Many contractors already work with the software and can even more easily combine GeoFrame with their own systems."

Size

For an architect, working with GeoFrame means that the outline of the shell is fixed. Woesthuis: "The usual way of working is that a developer or contractor is commissioned to build a series of houses or an entire residential area, and for this an architect provides a detailed final design. Any precast concrete skeleton is also drawn out in that. Any difference in dimensions in such a frame costs the contractor and precast manufacturer a lot of extra time and money in calculations. With GeoFrame we limit the choice somewhat, although you can still build almost anything, but the gain is significant. Moreover, the contractor can also include the MKI values to quickly calculate an MPG."

Linking Configuration

The website is clearly laid out with a configurator, a quotation module in which the contractor creates his own library and can see prices, and a module to add his own BIM files to the Geoframe design. "The contractor or architect can easily attach their own IFCs to the configuration, for example to add a particular facade," Woesthuis emphasizes. "They can then also view and share the result in a viewer. All housing designs end up in their own library and can be fitted into the plan configurator, which can be used to compile streets and neighborhoods. From that, too, GeoFrame can again create presentable images that can be shared with a client, for example."

For the contractor, several benefits are up for grabs when using GeoFrame. MBS obviously benefits as well. Woesthuis concludes: "We too save time in the engineering phase, but we can also achieve efficiency gains in the manufacturing process. The program can eventually be linked to our ERP system in order to control production directly. That is one of the next steps we are going to take."
