‘Busbar trunking systems ensure optimum power distribution at Jumbo’s NDC’

Text Lieke van ZuilekomImage Kromwijk Elektrotechniek

Vier stuks railkokers richting het dak, voor de aansluiting van de omvormers van de zonnepanelen, met op de voorgrond de noodverlichting.
Vier stuks railkokers richting het dak, voor de aansluiting van de omvormers van de zonnepanelen, met op de voorgrond de noodverlichting.

Jumbo’s new national distribution centre (NDC) in Nieuwegein stands out for its exceptionally high quality and sustainability, including in its electrical installations. Commissioned by Bouwbedrijf van de Ven and in accordance with the Programme of Requirements set by BREEAM experts W4Y and Da Vinci Vastgoed, Kromwijk Elektro is responsible for the engineering and installation of all electrical disciplines. Its work ranges from the transformers to the main and sub-distribution boards, lighting and sound systems, and connections for Witron’s mechanised system. The Woerden-based installer faced a number of challenges along the way.

“This project involved not only a high BREEAM-NL ambition, but also high power loads and long distances that had to be bridged,” says Adriaan van der Neut, co-owner of Kromwijk Elektro. “To ensure optimum power distribution throughout the building, we installed three separate power connections. Inside the building, we opted for busbar trunking systems, which make it easy to distribute high power loads over long distances without the risk of voltage drops.”

Three transformers were installed as part of the project. Busbar trunking effectively extends the main distribution boards to the points of use. “More than sixty tap-off boxes have been installed along the busbar routes, to supply power to the Witron system, among other things. To monitor energy performance, every circuit breaker is monitored using Schneider Electric’s Power Monitoring Expert (PME) system. This allows maintenance to be targeted more effectively, helping to prevent faults.”

Busbar trunking with tap-off boxes.

A total of 13,500 solar panels have been installed on the roof of the distribution centre, generating 4,000,000 kWh of solar power each year. Kromwijk Elektro used busbar trunking (waterproof/IP68) to distribute the power to the distribution boards. “LED lighting has also been installed throughout the building,” says Van der Neut. “Most of the project uses continuous-row LED lighting. This includes the warehouse areas, where we had to contend with considerable ceiling heights and a large number of racking units. LED recessed luminaires were selected for the offices, LED downlights for the corridors, and suitable LED luminaires for the entrance and restaurant.” All the luminaires have built-in intelligence, allowing Jumbo to control and monitor the lighting easily via DALI. “As well as the active status of the luminaires, driver temperatures and dimming levels, the system provides insight into operating hours. This can be used to further optimise the lighting plan, determine the expected service life of the luminaires and enable 100% predictable maintenance.”

TRILUX Benelux, the lighting supplier, provided the LiveLink Premium lighting management system, which allows the lighting to be controlled individually and/or by zone. “Occupancy sensors and daylight controls ensure that lights are never on unnecessarily,” says Van der Neut. “In future, lighting fixtures can also be added or removed easily as the needs of the spaces change.”
